- > Multi-spindle 5 faces millimg center OM-230/320/430
- > Robot combined multi-spindle 5 faces milling center OM-430R
Five faces of a work can be machined by one chucking by 4 axes control. Tools are fixed in line, without ATC. This brings highly accurate and high speed drilling, tapping, milling, of precision small works for OA equipments, optical euipments or watches,etc.
 |
 |
 |
| OM-230 Horizontal2-axes・Vertical3-axes | OM-320 Horizontal3-axes・Vertical2-axes | OM-430 Horizontal4-axes・Vertical3-axes |
| Item | OM-230 | OM-320 | OM-430 | |||
| Capacity | Work size(mm) | 100×100×100 | ||||
| Spindle Unit |
Number of tools | Horizontal | 2 | 3 | 4 | |
| Vertical | 3 | 2 | 3 | |||
| Distance between spindles(mm) | 120 | |||||
| Horizontal | Speed (min-1) | Max.7,000 | ||||
| Rigid speed | - | Max. 3,600 | Max. 3,600 | |||
| Collet | Rego fix ER32 φ20 | |||||
| Quill diameter (mm) | φ80 | |||||
| Vertical | Speed (min-1) | Max.7,000 | ||||
| Rigid speed | - | - | Max. 3,600 |
|||
| Collet | Rego fix ER32 φ20 | |||||
| Quill diameter | φ80 | |||||
| Column | Travel (mm) | X:270 Y:150 Z:150 | X:390 Y:150 Z:150 | |||
| Rapid traverse (m/min) | 12 | |||||
| Cutting feed rate (m/min) | 5,000 | |||||
| Traver:Least input incremental (mm) | 0.001 | |||||
| C axis | Table:Least input incremental (deg) | 0.001 | ||||
| Table rotation(Rapid traverse) [min-1] | 60 | |||||
| NC contril unit | FANUC 0i-MD | |||||
5 faces by one chuck machining with 4 axes CNC control.Robot combined multi-spindle 5 faces milling center.
A gantry scalar robot is built in the machine for supply and collection of workpieces.The robot runs near under the machine roof in the splash room and dose not need extra space.
The machine contributes to save floor space as its conventional model.
 |
 |
 |
| OM-430R Photo of inside the machine | OM-430R Photo of inside the machine | OM-430R Robot combined |
| Item | OM-430R | |||||
| Capacity | Work size | mm | 100×100×100 | |||
| Spindle Unit |
Number of tools | Horizontal | 4 | |||
| Vertical | 3 | |||||
| Distance between spindles | mm | 120 | ||||
| Horizontal | Speed | min-1 | Max.7,000 | |||
| Rigid speed | Max.3,600 | |
||||
| Collet | Rego fix ER32 φ20 | |||||
| Quill diameter | mm | φ80 | ||||
| Vertical | Speed | min-1 | MAx.7,000 | |||
| Rigid speed | Max.3,600 | |
||||
| Collet | Rego fix ER32 φ20 | |||||
| Quill diameter | φ80 | |||||
| Column | Travel | mm | X:390Y:150Z:150 | |||
| Rapid traverse | m/min | 12 | ||||
| Cutting feed rate | mm/min | 5,000 | ||||
| Traver:Least input incremental | mm | 0.001 | ||||
| C axis | Table:Least input incremental | deg | 0.001 | |||
| Table rotation(Rapid traverse) | min-1 | 60 | ||||
| NC contril unit | FANUC 0i-MD | |||||
